Gas Purifiers

The purpose of the MBRAUN gas purification system, together with a glovebox is for the enabling and maintaining of a pure inert gas atmosphere inside a hermetically sealed enclosure. We propose a wide range of gas purification system to remove O2 and H2O, but not only. Inert atmosphere is important, but a clean atmosphere too. We can remove solvent vapors, dust and hazardous particles, i.e. for Additive Manufacturing (3D Printing, LMD).

IGMS pro

  • Demanding and/or large enclosure volume
  • Dedicated to industrial application
  • Interface to customer control system
  • Modular construction
  • Solvent trap
  • Up to 220m³ enclosure volume

Inert Gas Purifiers (G-series)

  • For Standard enclosures
  • Removes O2/H2O <1ppm
  • Solvent trap as option
  • myMBRAUN
  • Easy to use
  • Up to 5m³

Clean jet

  • Effective dust and soot removal
  • Especially designed for reactive materials like titanium
  • Closed loop performance through gas tight connections
  • HEPA filter for best performance
  • Safe operation

Nitrogen Removal

  • Ensures no N2 in your enclosure
  • The gas purifier module MB-200-N-I removes N2 from Argon
  • Battery application

HP gas purifiers

  • Pre-purification of an in-house gas supply
  • Dry gas supply (inert gas) for purge boxes
  • Ideal to pre-purify gas when multiple gloveboxes are used

Clean Dry Air (CDA)

MBRAUN developed a series of gas purification systems specifically dedicated to the dehumidification of clean process air. Compared to other MBRAUN purifier models which remove oxygen too, the CDA units are entirely focused on moisture removal.

  • Very high H2O capacity
  • Very compact, space saving design
  • Very low energy consumption
  • Low operating costs
  • No requirement for regeneration gases
  • No influence of the regional climate changes

Humidifier

The MBRAUN glovebox humidifier is designed to provide an adjustable level (5-70%) of moisture for the connected equipment (usually a glovebox). The device acts as a generator of humidified gas and has its own circulation blower which provides a gas flow for the intermix of moist gas and the containment atmosphere. The principle of operation is based on evaporation of water droplets into a gas stream. Additional features are available for the direct humidifying of the filter or for dehumidification (purging or drying by filter)

Tritium Retention Systems (TRS)

Tritium Retention Systems (TRS) convert tritiated chemical species (principally elemental, oxide and hydrocarbon) in the process stream to the oxide form (HTO) and remove the tritiated water by adsorption on molecular sieve beds.

  • Tritium Oxidizing System
  • Water Capturing System
  • Worldwide Operating Capability Through Use of Standardized Power Supply
  • Incorporates High-vacuum Feedthroughs
